羅茨風機間隙規范，羅茨風機葉輪與各組件的間隙尺寸。經過掌握這種尺寸能夠在安裝使用時運行融洽和平穩。

　　1、羅茨風機葉輪與葉輪的間隙尺寸：

　　這兩個零配件中間的間隙在0.3mm~0.4mm

　　2、羅茨風機葉輪與外殼的間隙尺寸：

　　這兩個零配件中間的間隙在0.1mm~0.2mm

　　3、羅茨風機葉輪與側墻板的間隙尺寸：

　　這兩個零配件中間的間隙在0.2mm~0.3mm

　　4、羅茨風機同歩齒輪的齒合間隙尺寸：

　　這兩個零配件中間的間隙在0.07mm~0.15mm

　　這一尺寸針對生產廠家的工藝技術與技術性有一定的影響，技術成熟的離心風機廠家生產制造出的羅茨風機運行下去平穩，使用壽命長久。

　　風機葉片晃動間隙規范靜態數據標準偏差為:葉輪與葉輪中間的間隙0.4-~0.5mm，葉輪與葉殼中間的軸向間隙0.2~0.3mm，葉輪與左、右墻板中間的徑向間隙0.3~0.4mm(左墻板間隙務必超過右墻板間隙0.05mm之上)，同步齒輪的齒合間隙0.08~0.16mm

　　羅茨風機零配件間隙調節到是多少才好?

　　羅茨風機調節間隙，不一樣地方的間隙規范是不一樣的，只能在規范的范圍之內，設備才可以平穩的運行。因此在調節零配件間隙的情況下要按照下列的規范來實際操作，外殼間隙操縱在0.20—0.395中間;葉輪—葉輪間隙操縱在0.29—0.34中間;葉輪與前墻板徑向間隙操縱在0.12—0.18中間;葉輪與墻壁間隔應當在0.63—0.69范圍之內。

　　The clearance specification of Roots blower, the clearance dimension between Roots blower impeller and each component. After mastering this size, it can run harmoniously and stably during installation and use.

　　Clearance standard for Roots blower accessories

　　1. Clearance dimension between Roots blower impeller and impeller:

　　The gap between the two parts is 0.3mm~0.4mm

　　2. Gap dimension between Roots blower impeller and housing:

　　The gap between the two parts is 0.1mm~0.2mm

　　3. Gap dimension between Roots blower impeller and side wall panel:

　　The gap between the two parts is 0.2mm~0.3mm

　　4. Backlash dimension of Roots blower synchronizing gear:

　　The clearance between the two parts is 0.07mm~0.15mm

　　This dimension has a certain impact on the process technology and technicality of the manufacturer. Roots fans manufactured by mature centrifugal fan manufacturers run smoothly and have a long service life.

　　The standard deviation of the static data of the fan blade shaking clearance specification is: the clearance between the impeller and the impeller is 0.4-~0.5mm, the axial clearance between the impeller and the blade shell is 0.2~0.3mm, the radial clearance between the impeller and the left and right wallboards is 0.3~0.4mm (the left wallboard clearance must exceed the right wallboard clearance by more than 0.05mm), and the meshing clearance of the synchronous gear is 0.08~0.16mm

　　What is the clearance of Roots blower parts?

　　The gap regulation of Roots blower is different in different places. The equipment can operate smoothly only within the range of the specification. Therefore, in the case of adjusting the clearance of parts and accessories, the actual operation shall be carried out according to the following specifications, and the clearance of the shell shall be controlled between 0.20-0.395; The clearance between impeller and impeller is between 0.29 and 0.34; The radial clearance between the impeller and the front wall panel is controlled between 0.12 and 0.18; The distance between the impeller and the wall shall be within the range of 0.63-0.69.
